INTERIOR LED PRODUCTS
All-in-One Ultra Thin LED Display
ALTERNATIVE SOLUTION TO LCD WALLS
1080P
& 4K
CONTENT
FINE &
ULTRA FINE
PITCH
BRIGHT
& VIVID
ULTRA THIN,
ALL IN ONE
SOLUTION
EASY INSTALL
SERVICEABLE
PARTS
TECHNICAL
| NAME: | iCV108 |
| PIXEL PITCH: | 1.25mm |
| RESOLUTION: | 1,920 x 1,080 |
| BRIGHTNESS: | 1,500+ Nits |
| LED TYPE: | Flip Chip |
| REFRESH RATE: | 3,840 Hz |
| POWER*: | ≤ 600 Watts |
| SERVICE: | Front |
| HEIGHT: | 4’5″ (1,350mm) |
| WIDTH: | 7’10” (2,400mm) |
| DEPTH: | 1.18″ (28mm) |
| WEIGHT: | 220 Lbs (100 Kg) |
TECHNICAL
| NAME: | iCV136 |
| PIXEL PITCH: | 1.56mm |
| RESOLUTION: | 1,920 x 1,080 |
| BRIGHTNESS: | 1,500+ Nits |
| LED TYPE: | Flip Chip |
| REFRESH RATE: | 3,840 Hz |
| POWER*: | ≤ 900 Watts |
| SERVICE: | Front |
| HEIGHT: | 5’6″ (1,687mm) |
| WIDTH: | 9’11” (3,000mm) |
| DEPTH: | 1.18″ (28mm) |
| WEIGHT: | 320 Lbs (145 Kg) |
TECHNICAL
| NAME: | iCV163 |
| PIXEL PITCH: | 1.87mm |
| RESOLUTION: | 1,920 x 1,080 |
| BRIGHTNESS: | 1,500+ Nits |
| LED TYPE: | Flip Chip |
| REFRESH RATE: | 3,840 Hz |
| POWER*: | ≤ 1300 Watts |
| SERVICE: | Front |
| HEIGHT: | 6’8″ (2,025mm) |
| WIDTH: | 11’10” (3,600mm) |
| DEPTH: | 1.18″ (28mm) |
| WEIGHT: | 419 Lbs (190 Kg) |
TECHNICAL
| NAME: | iCV163-4K |
| PIXEL PITCH: | 0.9mm |
| RESOLUTION: | 3,840 x 2,160 |
| BRIGHTNESS: | 700+ Nits |
| LED TYPE: | 4-in-1 Mini LED |
| REFRESH RATE: | 3,840 Hz |
| POWER*: | ≤ 1100 Watts |
| SERVICE: | Front |
| HEIGHT: | 6’8″ (2,025mm) |
| WIDTH: | 11’10” (3,600mm) |
| DEPTH: | 1.18″ (28mm) |
| WEIGHT: | 419 Lbs (190 Kg) |
*Typical Power Consumption
EXTERIOR LED PRODUCTS
All-in-One Thin LED Display
OUTDOOR RATED LED DISPLAY
16:9
ASPECT
RATIO
IP65,
WEATHER-
PROOF
BRIGHT
& VIVID
THIN,
ALL IN ONE
SOLUTION
EASY INSTALL
SERVICEABLE
PARTS
TECHNICAL
| NAME: | eCV130 |
| PIXEL PITCH: | 1.6mm |
| RESOLUTION: | 1,800 x 1,000 |
| BRIGHTNESS: | 4,000+ Nits |
| LED TYPE: | Nationstar Gold Wire 1010 LED |
| REFRESH RATE: | 3,840 Hz |
| POWER*: | ≤ 720 Watts |
| SERVICE: | Front |
| HEIGHT: | 5’9″ (1,760mm) |
| WIDTH: | 9’6″ (2,889mm) |
| DEPTH: | 4.9″ (124mm) |
| WEIGHT: | 661.4 Lbs (300 Kg) |
TECHNICAL
| NAME: | eCV152 |
| PIXEL PITCH: | 1.9mm |
| RESOLUTION: | 1,764 x 1,008 |
| BRIGHTNESS: | 4,000+ Nits |
| LED TYPE: | Nationstar Gold Wire 1010 LED |
| REFRESH RATE: | 3,840 Hz |
| POWER*: | ≤ 1,000 Watts |
| SERVICE: | Front |
| HEIGHT: | 6’9″ (2,080mm) |
| WIDTH: | 11’1″ (3,369mm) |
| DEPTH: | 4.9″ (124mm) |
| WEIGHT: | 815.7 Lbs (370 Kg) |
TECHNICAL
| NAME: | eCV203 |
| PIXEL PITCH: | 2.5mm |
| RESOLUTION: | 1,792 x 1,024 |
| BRIGHTNESS: | 4,000+ Nits |
| LED TYPE: | Nationstar Gold Wire 1010 LED |
| REFRESH RATE: | 3,840 Hz |
| POWER*: | ≤ 1,200 Watts |
| SERVICE: | Front |
| HEIGHT: | 8’11” (2,720mm) |
| WIDTH: | 14’9″ (4,489mm) |
| DEPTH: | 4.9″ (124mm) |
| WEIGHT: | 1,212.5 Lbs (550 Kg) |
*Typical Power Consumption
